Static Compensators (STATCOMs) in Power Systems

A static compensator (STATCOM), also known as static synchronous compensator, is a member of the flexible alternating current transmission system (FACTS) devices. It is a power-electronics based regulating device which is composed of a voltage source converter (VSC) and is shunt-connected to alternating current electricity transmission and distribution networks. The voltage source is created from a DC capacitor and the STATCOM can exchange reactive power with the network. It can also supply some active power to the network, if a DC source of power is connected across the capacitor. A STATCOM is usually installed in the electric networks with poor power factor or poor voltage regulation to improve these problems. In addition, it is used to improve the voltage stability of a network.This book covers STATCOMs from different aspects. Different converter topologies, output filters and modulation techniques utilized within STATCOMs are reviewed. Mathematical modeling of STATCOM is presented in detail and different STATCOM control strategies and algorithms are discussed. Modified load flow calculations for a power system in the presence of STATCOMs are presented. Several applications of STATCOMs in transmission and distribution networks are discussed in different examples and optimization techniques for defining the optimal location and ratings of the STATCOMs in power systems are reviewed. Finally, the performance of the network protection scheme in the presence of STATCOMs is described. This book will be an excellent resource for postgraduate students and researchers interested in grasping the knowledge on STATCOMs.

Highlights recent research advancements in the area of Static Compensators (STATCOMs) and their applications in power systems Covers different topologies, and control strategies of STATCOMs in power systems Also highlights the integration of STATCOMs in the networks with renewable energy resources Includes supplementary material: sn.pub/extras

Autorentext

Dr. Farhad Shahnia received his Ph.D. in Electrical Engineering from Queensland University of Technology, Brisbane, Australia. He is currently a Lecturer in Curtin University, Perth, Australia. His professional experience includes three years at Research Office-Eastern Azerbaijan Electric Power Distribution Company, Tabriz, Iran. Prior to joining Curtin University, he was a research fellow in Queensland University of Technology, Brisbane, Australia. He has published 5 book chapters, 8 journal papers and 55 conference papers.

Dr. Sumedha Rajakaruna received his Ph.D. in Electrical Engineering from the University of Toronto, Ontario, Canada. He was a Lecturer at University of Moratuwa, Sri Lanka until 2000 and then an Assistant Professor at Nanyang Technological University, Singapore until 2007. Since 2007, he is at Curtin University, Perth, Australia. He is the founding Director and Lead Designer of Green Electric Energy Park at Curtin University, a state of the art renewable energy laboratory built at the cost of over $1.2 million in 2012. He is the supervisor of more than 10 PhD graduates and has published 2 book chapters and over 40 research articles.

Dr. Arindam Ghosh received his Ph.D. in Electrical Engineering from University of Calgary, Canada in 1983. Currently, he is a Professor of Power Engineering at Curtin University, Perth, Australia. Prior to joining the Curtin in 2013, he was with Queensland University of Technology, Brisbane, Australia from 2006 to 2012 and with the Department of Electrical Engineering at IIT Kanpur, India, for 21 years. He is a fellow of INAE and IEEE. He has published 1 book, 6 book chapters and more than 350 papers in international conferences and journals.

Inhalt

Converter and Output Filter Topologies for STATCOMs.- Multilevel Converter Topologies for STATCOMs.- Analysis and Implementation of an 84-pulse STATCOM.- Mathematical Modeling and Control Algorithms of STATCOMs.- STATCOM Control Strategies.- Robust Nonlinear Control of STATCOMs.- Versatile Control of STATCOMs using Multiple Reference Frames.- Control of Multilevel STATCOMs.- Adaptive Observer for Capacitor Voltages in Multilevel STATCOMs.- Modeling and Control of STATCOMs.- Study of STATCOM in abc Framework.- Modeling of STATCOM in Load Flow Formulation.
