This book provides a comprehensive description of microsensors for mechanical quantities (flow, pressure, force, inertia) fabricated by silicon micromachining. Since the design of such sensors requires interdisciplinary teamwork, the presentation is made accessible to engineers trained in electrical and mechanical engineering, physics and chemistry. The reader is guided through the micromachining fabrication process. A chapter on microsensor packaging completes the discussion of technological problems. The description of the basic physics required for sensor design includes the mechanics of deformation and the piezoresistive transduction to electrical signals. There is also a comprehensive discussion of resonant sensors, the hydrodynamics and heat transfer relevant for flow sensors, and, finally, electronic interfacing and readout circuitry. Numerous up-to-date case studies are presented, together with the working, fabrication and design of the sensors.

This book presents a microtechnology important for manufacturing, design and application of microdevices. It appeals to engineers and advanced students.

Gives an overview of the physics necessary to understand, design and fabricate mechanical microsensors Provides a guide to the relevant literature Discusses the advantages and limitations of microtechnology Includes supplementary material: sn.pub/extras

Klappentext
Fabrication technologies related to those which are exploited for the fabrication of integrated circuits can be used to machine mechanical structures with minimum feature sizes in the range of micrometers. The mechanical machining of silicon based on IC-technologies is known as micromachining, and the systems made by micromachining are called MEMS (microelectromechanical systems). The present book describes how to use this technology to fabricate sensors of miniature size for mechanical quantities, such as pressure, force, flow and acceleration. The book includes a chapter with a comprehensive description of the relevant micromachining processes, and an introduction to MEMS, a field much broader than just microsensors. Most of these sensors rely on a deformation of the mechanical construction by an external load, and on a transduction mechanism to convert the deformation into a mechanical signal. The fundamental mechanics and electromechanics required for the understanding and the design of mechanical microsensors are described on a level accessible to engineers of all disciplines. Students in engineering sciences from the third year on should be able to benefit from this description. The most important mechanical sensors are described and discussed in detail with respect to fabrication issues, function and performance. Special emphasis is given to pressure sensors, force sensors, accelerometers, gyroscopes and flow sensors. Electronic interfacing, and a discussion of electronic circuits used for the sensors is also included. Finally the problem of packaging is addressed.

Inhalt

1. Introduction.- 2. MEMS.- 2.1 Miniaturisation and Systems.- 2.2 Examples for MEMS.- 2.3 Small and Large: Scaling.- 2.4 Available Fabrication Technology.- 3. Introduction into Silicon Micromachining.- 3.1 Photolithography.- 3.2 Thin Film Deposition and Doping.- 3.3 Wet Chemical Etching.- 3.4 Waferbonding.- 3.5 Plasma Etching.- 3.6 Surface Micromachining.- 4. Mechanics of Membranes and Beams.- 4.1 Dynamics of the Mass Spring System.- 4.2 Strings.- 4.3 Beams.- 4.4 Diaphragms and Membranes.- 5. Principles of Measuring Mechanical Quantities: Transduction of Deformation.- 5.1 Metal Strain Gauges.- 5.2 Semiconductor Strain Gauges.- 5.3 Capacitive Transducers.- 6. Force and Pressure Sensors.- 6.1 Force Sensors.- 6.1.1 Load Cells.- 6.2 Pressure Sensors.- 7. Acceleration and Angular Rate Sensors.- 7.1 Acceleration Sensors.- 7.2 Angular Rate Sensors.- 8. Flow sensors.- 8.1 The Laminar Boundary Layer.- 8.2 Heat Transport in the Limit of Very Small Reynolds Numbers.- 8.3 Thermal Flow Sensors.- 8.4 Skin Friction Sensors.- 8.5 Dry Fluid Flow Sensors.- 8.6 Wet Fluid Flow Sensors.- 9. Resonant Sensors.- 9.1 Basic Principles and Physics.- 9.2 Excitation and Detection Mechanisms.- 9.3 Examples and Applications.- 10. Electronic Interfacing.- 10.1 Piezoresistive Sensors.- 10.2 Capacitive Sensors.- 10.3 Resonant Sensors.- 11. Packaging.- 11.1 Packaging Techniques.- 11.2 Stress Reduction.- 11.3 Pressure Sensors.- 11.4 Inertial Sensors.- 11.5 Thermal Flow Sensors.- References.
