Logic Synthesis for Compositional Microprogram Control Units

This book presents design methods for and hardware amount optimization for compositional microprogram control units (CMCU). It includes new models of control units, methods of their synthesis and a lot of examples.

One of the very important parts of any digital system is the control unit, coordin- ing interplay of other system blocks. As a rule, control units have irregular str- ture, which makes process of their logic circuits design very sophisticated. In case of complex logic controllers, the problem of system design is reduced practically to the design of control units. Actually, we observe a real technical boom connected with achievements in semiconductor technology. One of these is the development of integrated circuit known as the "systems-on-a-programmable- chip" (SoPC), where the number of elements approaches one billion. Because of the extreme complexity of microchips, it is very important to develop effective design methods oriented on particular properties of logical elements. Solution of this problem permits impr- ing functional capabilities of the target digital system inside single SoPC chip. As majority of researches point out, design methods used in case of industrial packages are, in case of complex digital system design, far from optimal. Similar problems concern the design of control units with standard ?eld-programmable logic devices (FPLD), such as PLA, PAL, GAL, CPLD, and FPGA. Let us point out that modern SoPC are based on CPLD or FPGA technology. Thus, the development of eff- tive design methods oriented on FPLD implementation of logic circuits used in the control units still remains the problem of great importance.

Klappentext

The control unit is one of the most important parts of any digital system. As a rule, control units have an irregular structure, which makes the processing of their logic circuits design very sophisticated. One possible way to optimise such characteristics such as the size or performance of control units is to adapt their structures to the particular properties of interpreted control algorithms. In this book control algorithms are represented by the linear graph-schemes of algorithms (GSA), where the number of operator vertices is not less than 75% of the total number of all algorithm vertices. A special class of control units named as compositional microprogram control units (CMCU) is proposed as the best way for interpretation of linear control algorithms. The CMCU includes a finite state machine, which addresses microinstructions of interpreted microprogram, and a microprogram control unit including control memory, which keeps only microoperations of initial GSA. The microprogram control unit uses the principle of natural addressing of microinstructions. Organization of the control unit proposed in the book increases regularity of the circuit, because the system of microoperations is implemented using standard blocks, such as PROM or RAM. At the same time, an irregular part of the system described by means of Boolean functions is reduced. It permits a decrease in the total number of logical elements (PAL, GAL, PLA, FPGA) in comparison with other models of finite state machines. The main goal of all proposed methods is reduction of the number of field-programmable logic devices used for implementation of logic circuit of the addressing FSM.

This book will be interesting and useful for students and postgraduates in the area of Computer Science and for designers of modern digital devices. Compositional microprogram control units enlarge the class of models applied for implementation of control units with modern field-programmable logic devices.

Inhalt
Methods of interpretation of control algorithms.- Synthesis of control units with field-programmable logic devices.- Synthesis of basic circuits of compositional microprogram control units.- Synthesis of compositional microprogram control units with code sharing.- Synthesis of compositional microprogram control units with object transformation.- Control memory optimization for compositional microprogram control units with code sharing.- Synthesis of CMCU with coding of logical conditions and collections of microoperations.- Synthesis of compositional microprogram control units with modified system of microinstructions.
