This book offers a novel approach to the analysis and design of all-digital phase-locked loops (ADPLLs), covering time-to-digital converters, noise shaping and more. Includes advice on analysis and simulation techniques, and reusable Matlab code.

Discusses in detail a wide range of all-digital phase-locked loops architectures Presents a unified framework in which to model time-to-digital converters for ADPLLs Explains a procedure to predict and simulate phase noise in oscillators and ADPLLs Describes an efficient approach to model ADPLLS Includes Simulink and Matlab code to reproduce the examples in the book Includes supplementary material: sn.pub/extras

Klappentext

This book presents a novel approach to the analysis and design of all-digital phase-locked loops (ADPLLs), technology widely used in wireless communication devices. The authors provide an overview of ADPLL architectures, time-to-digital converters (TDCs) and noise shaping. Realistic examples illustrate how to analyze and simulate phase noise in the presence of sigma-delta modulation and time-to-digital conversion. Readers will gain a deep understanding of ADPLLs and the central role played by noise-shaping. A range of ADPLL and TDC architectures are presented in unified manner. Analytical and simulation tools are discussed in detail. Matlab code is included that can be reused to design, simulate and analyze the ADPLL architectures that are presented in the book.

• Discusses in detail a wide range of all-digital phase-locked loops architectures;
• Presents a unified framework in which to model time-to-digital converters for ADPLLs;
• Explains a procedure to predict and simulate phase noise in oscillators and ADPLLs;
• Describes an efficient approach to model ADPLLS;
• Includes Matlab code to reproduce the examples in the book.

Inhalt
Introduction.- Phase Digitization in All-Digital PLLs.- A Unifying Framework for TDC Architectures.- Analytical Predictions of Phase Noise in ADPLLs.- Advantages of Noise Shaping and Dither.- Efficient Modeling and Simulation of Accumulator-Based ADPLLs.- Modelling and Estimating Phase Noise with Matlab.
