Applied Scanning Probe Methods XII

This volume examines the physical and technical foundation for progress in applied scanning probe techniques. It first introduces scanning probe microscopy, including sensor technology and tip characterization, and then details various industrial applications.

Crack initiation and growth are key issues when it comes to the mechanical reliab- ity of microelectronic devices and microelectromechanical systems (MEMS). Es- cially in organic electronics where exible substrates will play a major role these issues will become of utmost importance. It is therefore necessary to develop me- ods which in situ allow the experimental investigation of surface deformation and fracture processes in thin layers at a micro and nanometer scale. While scanning electron microscopy (SEM) might be used it is also associated with some major experimental drawbacks. First of all if polymers are investigated they usually have to be coated with a metal layer due to their commonly non-conductive nature. Additi- ally they might be damaged by the electron beam of the microscope or the vacuum might cause outgasing of solvents or evaporation of water and thus change material properties. Furthermore, for all kinds of materials a considerable amount of expe- mental effort is necessary to build a tensile testing machine that ts into the chamber. Therefore, a very promising alternative to SEM is based on the use of an atomic force microscope (AFM) to observe in situ surface deformation processes during straining of a specimen. First steps towards this goal were shown in the 1990s in [14] but none of these approaches truly was a microtensile test with sample thicknesses in the range of micrometers. To the authors' knowledge, this was shown for the rst time by Hild et al. in [5]. 16.

First book summarizing the state of the art of this technique Real industrial applications included Includes supplementary material: sn.pub/extras

Autorentext
Harald Fuchs, Jahrgang 1954 und Vater von drei Kindern, lebt in Pforzheim. Er arbeitete viele Jahre selbstständig in der Werbebranche, bis er sich 2004 umorientierte und unter anderem eine Ausbildung als Elektrobiologe absolvierte. 2008 begann er, sein Wissen auf eigenen Vorträgen und Seminaren an die Menschen weiterzugeben. Technologische sowie gesellschaftliche Entwicklungen und Veränderungen stehen dabei stets im Mittelpunkt seiner Betrachtungen.

Inhalt
Direct Force Measurements of ReceptorLigand Interactions on Living Cells.- Imaging Chemical Groups and Molecular Recognition Sites on Live Cells Using AFM.- Applications of Scanning Near-Field Optical Microscopy in Life Science.- Adhesion and Friction Properties of Polymers at Nanoscale: Investigation by AFM.- Mechanical Characterization of Materials by Micro-Indentation and AFM Scanning.- Mechanical Properties of Metallic Nanocontacts.- Dynamic AFM in Liquids: Viscous Damping and Applications to the Study of Confined Liquids.- Microtensile Tests Using In Situ Atomic Force Microscopy.- Scanning Tunneling Microscopy of the Si(111)-7×7 Surface and Adsorbed Ge Nanostructures.
