This book is the sixth in the ChDL (Chip Design Languages) series. Year 2004 has seen many efforts in the ?eld of electronic and mixed technology circuit design languages. The industry has recognized the need for system level design as a way to enable the design of the next generation of emb- ded systems. This is demonstrated by the ESL Now! campaign that many companies are promoting. This year has also seen many interesting st- dardization efforts for system level design, such as SystemC TLM for transactional level modeling with SystemC, AU- TOSAR for automotive embedded system - plications, or SPIRIT for IP int- change. In the ?eld of modeling languages, the Model Driven Architecture of the OMG has given rise to model driven en- neering, which is a more general way of software engineering based on model transformations. As embedded systems are more and more programmable and as the design abstraction level rises, model driven methodologies are also c- sidered for electronic system level design. In this context, the OMG has - cently published a call for propositions for a UML 2. 0 pro?le for Modeling and Analysis of Real-Time and Embedded systems (MARTE). The constraints on the design process of these next generation embedded systems are considerable: Real-time, power consumption, complexity, mixed technology integration, correctness, time to market, cost, . . .

Latest research results Covers all the field of languages and methods for system design Peer reviewed selection of best papers from the HDLCon and FDL conferences Includes supplementary material: sn.pub/extras

Inhalt
Analog and Mixed-Signal Systems.- Refinement of Mixed-Signal Systems: Between Heaven and Hell.- Mixed Nets, Conversion Models, and VHDL-AMS.- Monte Carlo Simulation Using VHDL-AMS.- Early Prediction of Conducted-Mode Emission of Complex Ic's.- Practical Case Example of Inertial Mems Modeling with VHDL-AMS.- UML-Based System Specification and Design.- Metamodels and MDA Transformations for Embedded Systems.- Model Based Testing and Refinement in MDA Based Development.- Predictability in Real-Time System Development.- Timing Performances of Automatically Generated Code Using MDA Approaches.- UML-Executable Functional Models of Electronic Systems in the VIPERS Virtual Prototyping Methodology.- C/C++-Based System Design.- Designing for Dynamic Partially Reconfigurable FPGAS with Systemc and OSSS.- Heterogeneous System-Level Specification in Systemc.- xHDL: Extending VHDL to Improve Core Parameterization and Reuse.- Systemc Models for Realistic Simulations Involving Real-Time Operating System Services.- Systemc and OCAPI-XL Based System-Level Design for Reconfigurable Systems-on-Chip.- Invited Contributions.- Symbolic Model Checking and Simulation with Temporal Assertions.- Automotive System Design and Autosar.
