This book describes two target applications for synchronous systems: regulated 3-phase voltage supply and voltage sag mitigation. It presents a detailed design procedure for converter switches and filters considering all steady-state, commutation and dynamic requirements. This work has evolved from previously published research by the authors, which in turn is part of a larger effort to expand the application domain of matrix converters to power systems. The objectives of the work have been categorized into the following: developing a dynamic model that provides adequate design insights; designing filters; and devising a control scheme. The low frequency dynamic model is first analyzed for regulated voltage supplies assuming balanced system. The system is modeled relative to a synchronous rotating (dq) frame linearized around an operating point. The input-output variables are related by non-diagonal transfer function matrices. Individual transfer function sub-matrices are sequentiallyinvestigated and it is shown that, depending on the input power, input voltage and filter parameters, the appearance of a set of right half zeros is possible. The book then considers filter design, as well as general issues like ripple attenuation, regulation, reactive current loading, and filter losses. The book also addresses additional constraints that may be imposed by dynamic requirements and commutation. In the third stage, voltage controller design is detailed for a 3-phase regulated voltage supply. In dq domain, output voltage control represents a multivariable control problem. This is reduced to a single variable control problem while retaining all possible right half zeros, thereby preserving the internal stability of the system. Consequently, the standard single variable control design technique has been used to design a controller. The analytically predicted dynamic response has been verified by experimental results. It was possible to operate the system beyond the critical power boundary where the right half zeros emerge. Lastly, the developed control approach has been extended to voltage sag mitigation with adequate modifications. A 3-wire linear load and both symmetrical and asymmetrical voltage sags have been considered. Experimentally obtained response time for sag mitigation was found to be less than the power supply holdup time of most of the sensitive equipment. This book will be useful to both researchers and graduate students.

Autorentext

Dr. Anindya Dasgupta is Assistant Professor of Avionics at the Indian Institute of Space Science and Technology, Thiruvananthapuram. Dr. Dasgupta received his PhD (Electrical Engineering) from the Indian Institute of Technology (IIT) Kanpur, India. He completed his M.E. (Control System, Electrical Engineering) in 2006 at Bengal Engineering and Science University, Shibpur and B. E. (Electrical Engineering) in 2000 at the Jadavpur University, Kolkata.

Dr. Parthasarathi Sensarma is Associate Professor of Electrical Engineering at IIT Kanpur, India. Dr. Sensarma completed his PhD (Electrical Engineering) in 2001 at the Indian Institute of Science (IISc), Bangalore, India. He was awarded his M. Tech (Machine Drives and Power Electronics) in 1992 from IIT Kharagpur and B. E. E (Electrical  Engineering) in 1990 from Jadavpur University, Kolkata. He has supervised several PhD and M.Tech. students. Dr. Sensarma has filed patent application at the Indian Patent Office for seven of his projects. He has published 56 technical papers in national and international conferences and journals.

Inhalt

Introduction.- Low frequency dynamic model.- Filter design.- Controller design for regulated voltage supply.- Voltage sag mitigation.- Conclusion.- Derivations associated with low frequency dynamic model.- 3 Phase Direct Matrix Converter prototype.- Phase Locked Loop.
