Generalized Low-Voltage Circuit Techniques for Very High-Speed Time-Interleaved Analog-to-Digital Converters

This detailed book presents new techniques tailored for low-voltage and high-speed Switched-Capacitor (SC) ADC with various design-specific considerations. It includes innovative solutions that enable the implementation of ADCs in low-voltage environments.

Analog-to-Digital Converters (ADCs) play an important role in most modern signal processing and wireless communication systems where extensive signal manipulation is necessary to be performed by complicated digital signal processing (DSP) circuitry. This trend also creates the possibility of fabricating all functional blocks of a system in a single chip (System On Chip - SoC), with great reductions in cost, chip area and power consumption. However, this tendency places an increasing challenge, in terms of speed, resolution, power consumption, and noise performance, in the design of the front-end ADC which is usually the bottleneck of the whole system, especially under the unavoidable low supply-voltage imposed by technology scaling, as well as the requirement of battery operated portable devices. Generalized Low-Voltage Circuit Techniques for Very High-Speed Time-Interleaved Analog-to-Digital Converters will present new techniques tailored for low-voltage and high-speed Switched-Capacitor (SC) ADC with various design-specific considerations.

Detailed mathematical analysis in the various imperfections in the design of the data converters Comprehensive analysis on the various low-voltage analog circuits techniques, and their trade-offs Innovative solutions that enable the implementation of ADCs in low-voltage environments This book is based on the practical works published in IEEE Int. Journals, ensure high-level peer-reviewed contents

Autorentext

Dr. Sin is currently the Secretary of IEEE Solid-State Circuit Society (SSCS) Macau Chapter, and Treasurer/Secretary of IEEE Macau CAS/COM Joint Chapter and the Member of Executive Committee Academic Affair of IEEE Macau, and has been the member of Technical Program and Organization Committee of the 2004 IEEJ AVLSI Workshop, Technical Session Chair of 2006 RIUPEEEC Conference, as well as the Special Session Co-Chair and Technical Program Committee Member of 2008 IEEE APCCAS Conference, Referee of IEEE Transaction of Instrumentation and Measurement and IEEE ISCAS Conference. He received the Chipidea Microelectronics Prize Postgraduate Level in 2008 for outstanding Academic and Research achievements in Microelectronics, as well as the Financial Support Award for Student Paper Contest in 2005 International Symposium on Circuits and Systems (ISCAS) held in Kobe, Japan, the Paper with Certificate of Merit for the 2006 RIUPEEEC Conference, as well as Award of Dean Honor List, Faculty of Science and Technology, University of Macau, in 1999-2000 and 2000-2001 respectively.

Dr. U is currently Senior Member of IEEE, the Industrial Relationship Officer of IEEE Macau Section and the Chairman of IEEE Macau CAS/COMM and SSC chapters. He has been with technical review committee of various IEEE journals and conferences. He was the chairman of the local organization committee of IEEJ AVLSIWS'04, Technical Program co-Chair of IEEE APCCAS'08. He is also the Program Co-chair of ICICS'09 and Technical Program Committee of ASSCC.

Prof. Rui Martins is an IEEE Fellow, was the Founding Chairman of the IEEE Macau Section from 2003 to 2005, and of the IEEE Macau Joint-Chapter on Circuits And Systems (CAS) / Communications (COM) from 2005 to 2008 [World Chapter of the Year 2009 of the IEEE Circuits And Systems Society (CASS)]. He was the General Chair of the 2008 IEEE Asia-Pacific Conference on Circuits And Systems APCCAS'2008, and was elected Vice-President for the Region 10 (Asia, Australia, the Pacific) of the IEEE Circuits And Systems Society (CASS), for the period of 2009 to 2010. He is Associate Editor of the IEEE Transactions on Circuits and Systems II Express Briefs,for the period of 2010 to 2011. He was the recipient of 2 government decorations: the Medal of Professional Merit from Macao Government (Portuguese Administration) in 1999, and the Honorary Title of Value from Macao SAR Government (Chinese Administration) in 2001.

Inhalt
Dedication. Preface. Acknowledgements. List of Abbreviations. 1 Introduction. 2 Challenges in Low-Voltage Circuit Designs. 3 Advanced Low Voltage Circuit Techniques. 4 Time-Interleaving: Multiplying the Speed of the ADC. 5 Design of a 1.2V, 10-bit, 60-360MHz Time-Interleaved Pipelined ADC. 6 Experimental Results. 7 Conclusions and Prospective for Future Work. Appendix 1 Operation Principle of VG-CMFB with O-CMEC. Appendix 2 Mathematical Analysis of Bandwidth Mismatches. Appendix 3 Noise Analysis of Advanced Reset-Opamp Circuits. Appendix 4 Special Case in Gain mismatch.
