Nanoscale Characterisation of Ferroelectric Materials

Among the main trends in our daily society is a drive for smaller, faster, cheaper, smarter computers with ever-increasing memories. To sustain this drive the com puter industry is turning to nanotechnology as a source of new processes and func tional materials, which can be used in high-performance high-density electronic systems. Researchers and engineers have been focusing on ferroelectric materials for a long time due to their unique combination of physical properties. The ability of ferroelectrics to transform electromagnetic, thermal, and mechanical energy into electrical charge has been used in a number of electronic applications, most recently in nonvolatile computer memories. Classical monographs, such as Ferro electricity by E. Fatuzzo and W. J. Mertz, served as a comprehensive introduction into the field for several generations of scientists. However, to meet the challenges of the "nano-era", a solid knowledge of the ferroelectric properties at the nano scale needs to be acquired. While the science of ferroelectrics from micro-to lar ger scale is well established, the science of nanoscale ferroelectrics is still terra in cognita. The properties of materials at the nanoscale show strong size dependence, which makes it imperative to perform reliable characterization at this size range. One of the most promising approaches is based on the use of scanning probe microscopy (SPM) which has revolutionized materials research over the last dec ade.

First one on nanoscale characterization of ferroelectric materials Includes supplementary material: sn.pub/extras

Inhalt
1 Electric Scanning Probe Imaging and Modification of Ferroelectric Surfaces.- 2 Challenges in the Analysis of the Local Piezoelectric Response.- 3 Electrical Characterization of Nanoscale Ferroelectric Structures.- 4 Nanoscale Optical Probes of Ferroelectric Materials.- 5 Scanning Nonlinear Dielectric Microscopy for Investigation of Ferroelectric Polarization.- 6 Nanoscale Piezoelectric Phenomena in Epitaxial PZT Thin Films.- 7 Scanning Probe Microscopy of Ferroelectric Domains near Phase Transitions.- 8 Nanodomain Engineering in Ferroelectric Crystals Using High Voltage Atomic Force Microscopy.- 9 Nanoinspection of Dielectric and Polarization Properties at Inner and Outer Interfaces in PZT Thin Films.
