This book describes the analysis and design of precision temperature sensors in CMOS IC technology, focusing on so-called smart temperature sensors, which provide a digital output signal that can be readily interpreted by a computer. The text shows how temperature characteristics can be used to obtain an accurate digital temperature reading. The book ends with a detailed description of three prototypes, one of which achieves the best performance reported to date.

The low cost and direct digital output of CMOS smart temperature sensors are important advantages compared to conventional temperature sensors. This book addresses the main problem that nevertheless prevents widespread - plication of CMOS smart temperature sensors: their relatively poor absolute accuracy. Several new techniques are introduced to improve this accuracy. The effectiveness of these techniques is demonstrated using three prototypes. ? The ?nal prototype achieves an inaccuracy of±0.1 C over the military t- perature range, which is a signi?cant improvement in the state of the art. Since smart temperature sensors have been the subject of academic and industrial research for more than two decades, an overview of existing knowledge and techniques is also provided throughout the book. Inthisintroductorychapter,themotivationandobjectivesofthisworkare- scribed. ThisisfollowedbyareviewofthebasicoperatingprinciplesofCMOS smart temperature sensors, and a brief overview of previous work. The ch- lenges are then described that need to be met in order to improve the accuracy of CMOS smart temperature sensors while maintaining their cost advantage. Finally, the structure of the rest of the book is introduced.

Gives a complete overview of temperature sensor design from physics to realizations Describes in detail state-of-the-art realizations of smart temperature sensors, including a ± 0.1° C accurate sensor Pays special attention to production aspects, such as calibration and trimming Includes a chapter devoted to the application of sigma-delta analog-to-digital converters in smart sensors Includes a chapter devoted to precision readout techniques, including dynamic offset cancellation and dynamic element matching

Autorentext

Prof. Johan Huijsing has (co) authored and edited over 20 books with Springer / Kluwer.

Dr. Michiel Pertijs graduated "cum laude" for his PhD work on the Temperature Sensor

Inhalt

Acknowledgment.- 1. Introduction.- 2. Characteristics of Bipolar Transistors.- 3. Ratiometric Temperature Measurement Using Bipolar Transistors.- 4. Sigma-Delta Analog-To-Digital Conversion.- 5. Precision Circuit Techniques.- 6. Calibration Techniques.- 7. Realizations.- 8. Conclusions.- Appendices. A Derivation of Mismatch-Related Errors. A.1 Errors in DV BE B Resolution Limits of Sigma-Delta Modulators with a DC Input. C Non-Exponential Settling Transients.- About the Authors.- Index.
