Ultra Low Power Transceiver for Wireless Body Area Networks

This book presents concepts and architectures for power use, wireless links, and circuit design for Wireless Body Area Networks, which will allow new applications for the ambulatory health monitoring of chronic disease patients and the elderly population.

Wireless Body Area Networks (WBANs) are expected to promote new applications for the ambulatory health monitoring of chronic patients and elderly population, aiming to improve their quality of life and independence. These networks are composed by wireless sensor nodes (WSNs) used for measuring physiological variables (e.g., glucose level in blood or body temperature) or controlling therapeutic devices (e.g., implanted insulin pumps). These nodes should exhibit a high degree of energy autonomy in order to extend their battery lifetime or even make the node supply to rely on harvesting techniques. Typically, the power budget of WSNs is dominated by the wireless link and, hence, many efforts have been directed during the last years toward the implementation of power efficient transceivers.

Because of the short range (typically no more than a few meters) and low data rate (typically in between 10 kb/s and 1 Mb/s), simple communication protocols can be employed. One of these protocols, specifically tailored for WBAN applications, is the Bluetooth low energy (BLE) standard.

This book describes the challenges and solutions for the design of ultra-low power transceivers for WBANs applications and presents the implementation details of a BLE transceiver prototype. Coverage includes not only the main concepts and architectures for achieving low power consumption, but also the details of the circuit design and its implementation in a standard CMOS technology.

Guides readers through the design of ultra low power transceivers for body area networks, from architecture to circuit-level implementation Describes 4 key strategies for ultra-low power transceiver design and specific, innovative techniques for circuit-level design Enables readers to design transceivers for body area networks with a total TX efficiency of 27% and an RX power consumption close to 1mW Includes a review of the state-of-the-art in low-power transceivers in the GHz frequency range Includes supplementary material: sn.pub/extras

Klappentext

This book describes the design of ultra low power transceivers for body area networks. Since these applications have very limited energy resources, typically powered only by tiny batteries or through energy harvesting techniques, this book describes an architecture for a Bluetooth low energy transceiver to overcome these limitations. Coverage includes not only the main concepts for achieving low power consumption, but also the details of the circuit design and its implementation in a standard CMOS technology.

· Guides readers through the design of ultra low power transceivers for body area networks, from architecture to circuit-level implementation;

· Describes 4 key strategies for ultra-low power transceiver design and specific, innovative techniques for circuit-level design;

· Enables readers to design transceivers for body area networks that are 27% more energy efficient than those currently available;

· Includes a review of the state-of-the-art in low-power transceivers in the GHz frequency range.

Inhalt
Introduction.- Review of the state of the art.- Low power strategies.- Implementation of the low power transceiver.- Co-integration of RF energy harvesting.- Conclusions.
