This book analyzes multi-MHz high frequency resonant DC-DC power converters with operating frequencies ranging from several MHz to tens of MHz in detail, aiming to support researchers and engineers with a focus on multi-MHz high frequency converters. The inverter stage, rectifier stage, matching network stage are analyzed in detail. Based on the three basic stages, typical non-isolated and isolated resonant DC-DC converters are depicted. To reduce the high driving loss under multi-MHz, resonant driving methods are introduced and improved. Also, the design and selection methods of passive and active component under multi-MHz frequency are described, especially for aircore inductor and transformer. Furthermore, multi-MHz resonant converter provides an approach for achieving flexible system.

Provides comprehensive resonant circuit design descriptions for MHz power converters Describes optimal design methods for magnetic components used in MHz power converters Presents a low-loss resonant driving method for MHz power converters

Autorentext

Guoqiang Zhang received Ph.D. degrees in electrical engineering from the Harbin Institute of Technology, Harbin, in 2017. Since then, he has been with the Department of Electrical Engineering, Harbin Institute of Technology, where he is currently an associate professor. His current research interests include control of electrical drives and parameter identification techniques, with the main focus on sensorless field-oriented control of synchronous motor drives. Dr. Zhang also serves as an associate editor for the Journal of Power Electronics. Gaolin Wang received the B.S., M.S., and Ph.D. degrees in Electrical Engineering from Harbin Institute of Technology, Harbin, China, in 2002, 2004, and 2008, respectively. In 2009, he joined the Department of Electrical Engineering, Harbin Institute of Technology, as a lecturer, where he has been a professor of Electrical Engineering since 2014. From 2009 to 2012, he was a postdoctoral fellow in Shanghai STEP Electric Corporation. He has authored more than 100 technical papers published in journals and conference proceedings (>50 IEEE Transactions papers). He is the holder of 20 Chinese patents. His current major research interests include AC motor drives. Dr. Wang serves as a guest editor of IEEE Transactions of Industrial Electronics, an associate editor for IEEE Access, IET Electric Power Applications and Journal of Power Electronics. He obtained the First Prize of science and technology progress of Heilongjing Province in 2019 and the Second Prize of science and technology progress of Ministry of Education in 2019. He was the recipient of the Outstanding Research Award and the Delta Young Scholar Award from the Delta Environmental and Educational Foundation in 2012 and 2014, respectively. He has been supported by the National Natural Science of China for Excellent Young Scholars. He published a book named "Position Sensorless Control Techniques for Permanent Magnet Synchronous Machine Drives" inSpringer in 2019. Nannan Zhao received the B.S. and M.S. degrees in control science and engineering in 2013 and 2015, and the Ph.D. degree in electrical engineering in 2019, all from Harbin Institute of Technology. Currently, he is a postdoctoral fellow and a lecturer in the School of Electrical Engineering and Automation, Harbin Institute of Technology. He has authored more than 25 technique papers (14 IEEE Transactions papers) in the field of AC motor drives. His current research interests include advanced control of permanent magnet synchronous motor drives and position sensorless control of AC motors. He is an IEEE member and supported by Postdoctoral Innovative Talent Support Program of China in 2019. He is nominated for the young engineer award of PCIM Asia 2020 and serves as the special session chair of reduced DC-link capacitance motor drives in IPEMC 2020. Dianguo Xu received the B.S. degree in control engineering from Harbin Engineering University, Harbin, China, in 1982, and the M.S. and Ph.D. degrees in electrical engineering from the Harbin Institute of Technology (HIT), Harbin, in 1984 and 1989, respectively. In 1984, he joined the Department of Electrical Engineering, HIT, as an assistant professor, where since 1994, he has been a professor. He was the dean of the School of Electrical Engineering and Automation, HIT, from 2000 to 2010. He is currently the vice-president with HIT. He has published more than 600 technical papers. His research interests include renewable energy generation technology, power quality mitigation, sensorless vector-controlled motor drives, and high-performance PMSM servo systems. Dr. Xu is an associate editor of the IEEE Transactions on Industrial Electronics, the IEEE Transactions on Power Electronics, and the IEEE Journal of Emerging and Selected Topics in Power Electronics. He serves as the chairman of the IEEE Harbin Section. He received the IEEE Industry Applications Society Outstanding Achievement Award in 2018.

Inhalt
Introduction.- Single switch SEPIC type converter.- Half-bridge high order resonant converter.- Full resonant inverter design.- Full resonant rectifier design.- Passive matching network.- Active matching network.- Magnetic-core magnetic component design.- Air-core magnetic component design.- Resonent driving method.
