Dieses Buch führt in alle Aspekte der sicheren Berechnung, Bemessung und Konstruktion von wirtschaftlichen modernen Verbindungen im Stahlbau ein. Die Hintergrunderläuterungen sind nicht an eine spezifische Norm gekoppelt, sondern es werden unterschiedliche Normen und Methoden verglichen, die in der Praxis zur Anwendung kommen, wie z. B. Eurocode, AISC, DIN, BS. Anhand einer Reihe von Beispielen werden Problemlösungen detailliert beschrieben und illustriert. Damit erhält der Leser alle notwendigen Werkzeuge an die Hand, um auch komplexe Probleme bei der Konstruktion von Verbindungen zu lösen.
Das Buch ist für Berufseinsteiger, für erfahrene Praktiker sowie auch für Stahlbaufachleute eine Arbeitshilfe, denn es werden einfache und komplexe Beanspruchungen an Verbindungen abgebildet. Weniger ausführlich werden Erdbebenauslegung, Schweißnähte, die Wechselwirkung mit anderen Materialien (Beton, Holz) und kalt geformte Verbindungen behandelt.

Autorentext
Alfredo Boracchini, PE is a registered engineer in Italy and in some states of the USA. His professional experience is focused on steel structures, he has designed and engineered in various construction sectors worldwide. He´s the owner of a professional engineering firm with branches in Europe, Asia and America as well as an active member in international associations. This allowed him to develop a broad international experience that he shares by means of this book with those interested in the design of bolted joints of steel structures.

Inhalt
Preface
Abbreviations
Introduction
1 Structural design basic principles relative to joints in steel structures
1.1 Hinges and joints capable of resisting a bending moment
1.2 The plastic hinge
2 Basic concepts for the analysis of connections
2.1 Connection types
2.2 Outline of design and actions
2.3 Forces distribute proportionally to stiffness
2.4 Ductility
2.5 Load path
2.6 Ignorance of the path of the forces
2.7 Constraints
2.8 Methods to define the ultimate limit states in the joints
2.9 Resistance of bolts
2.10 Yield line
2.11 Eccentric connections
2.12 Economics, repetition, simplicity
2.13 Man-hours, material weight
2.14 Diffusion angles
2.16 Transfer forces
2.15 Tensioning of bolts and resistance
2.17 Behavior of a bolted joint shear
2.18 Behavior of a bolted joint in traction
3 The limit states for the components of the connection
3.1 Capacity of deformation (rotation) and relative stiffness
3.2 Inelastic deformations at the bolt hole
3.3 Bolt shear rupture
3.4 Bolt tensile rupture
3.5 Breaking bolt with a combination of tension and shear
3.6 Resistance to friction bolts
3.7 Bolt bearing and tearing
3.8 Block shear (or block tearing)
3.9 Weld rupture
3:10T-stub, with and without prying effect
3.11 Punching shear
3.12 Equivalent systems in parallel
3:13 Web panel shear
3.14 Transversal compression over web
3:15 Transversal tension over column web
3.16 Web and flange compression
3:17 Tension on beam web
3.18 Plate resistance
3.19 Notched profiles
3.20 Local capacity
3:22 Structural integrity
3.23 Ductility
3:24 Laminated plate tearing
3.25 Other states limit in connection with cold formed profiles or sheets
3.26 Fatigue
3:27 Limit states for other connected related materials
4 types and analysis with calculation examples
4.1 Common symbols
4.2 Eccentric bolted joint in the plane of contact
4.3 Eccentric bolted connection perpendicular to the contact plane gravity method
4.4 Base plate with cast anchor bolts
4.5 chemical or mechanical anchors
4.6 Fin plate
4.7 Double bolted plate
4.8 Flexible end plate
4.9 Clip angles
4:10 Truss joints
4.10.1 connecting plate
4:11 Connection leaning on a column
4:12 Rigid end plate
4:13 Splice
4.13.1 calculation model and limit states
4.13.2 rotation capacity, structural integrity, ductility
4.13.3 column splice example according to is800
4:14 Brace joints
4.14.1 american methods: ufm and kiss
4.14.2 practical advice
4.14.3 bracing friction connection example according to csa s16
4.15 Chair support
4.16 Connections for purlins
4:17 Tubular welded joints
4:18 Joints in steel-concrete composite structures
4:19 joints with welding and bolting working in parallel
4:20 Expansion joints
4:21 Perfect hinges
4:22 Sliding details
4:23 Rivets
4:24 Joints for seismic applications
4.24.1 rigid end plate
4.24.2 braces
4.24.3 eccentric braces with "link"
4.24.4 base plate
5 selection of the right connection
5.1 Priority to those who produce and erect
5.2 Considerations about the pros and cons of the various connection types
5.3 Organization of the workshop
5.3.1 plates or sheets
5.3.2 concept of "picking up a piece"
5.4 Cultural elements
6 tips, notes and practices
6.1 Project standardization
6.2 Hole dimensions
6.3 Installation
6.4 Maneuvering
6.5 Spacing and distances between bolts
6.6 Root radius overlap
6.7 Notches
6.8 Pretensioning
6.9 Washers
6:10 Dimensions for screws, nuts and washers
6.11 Reusing bolts
6.12 Bolts classes
6:13 Shims
6:14 Galvanization
6.15 Other treatments after manufacturing
6:16 Camber
6:17 Grouting base plates
6.18 Graphical representation of joints and bolts
6:19 Field welding
6:20 Special couplings (inclined)
7 Sketches of possible joint applications
Bibliography
Index of tables
Index
