Substrate integrated waveguide (SIW) is a new type of transmission line. It implements a waveguide on a piece of printed circuit board by emulating the side walls of the waveguide using two rows of metal posts. It inherits the merits both from the microstrip for compact size and easy integration, and from the waveguide for low radiation loss, and thus opens another door to design efficient microwave circuits and antennas at a low cost. This book presents a two-dimensional fullwave analysis method to investigate an SIW circuit composed of metal and dielectric posts. It combines the cylindrical eigenfunction expansion and the method of moments to avoid geometrical descritization of the posts. The method is presented step-by-step, with all the necessary formulations provided for a practitioner who wants to implement this method by himself. This book covers the SIW circuit printed on either homogeneous or inhomogeneous substrate, the microstrip-to-SIW transition and the speed-up technique for the simulation of symmetrical SIW circuits. Different types of SIW circuits are shown and simulated using the proposed method. In addition, several slot antennas and horn antennas fabricated using the SIW technology are also given. Table of Contents: Introduction / SIW Circuits Composed of Metallic Posts / SIW Circuits with Dielectric Posts / Even-Odd Mode Analysis of a Symmetrical Circuit / Microstrip to SIW Transition and Half Mode SIW / SIW Antennas

Autorentext

Xuan Hui Wu received the B.Eng. degree from the Department of Information Science & Electronic Engineering (ISEE), Zhejiang University, China, in 2001, the M.Eng. degree from the Department of Electrical and Computer Engineering (ECE), National University of Singapore, Singapore, in 2005, and the Ph.D. degree from the Department of Electrical Engineering, University of Mississippi, USA. From 2002 to 2004, he is with the Institute for Infocomm Research (I2R), Agency of Science Technology and Research, Singapore, as a Research Graduate Student. From 2004 to 2009, he is with the Microwave Research Laboratory, University of Mississippi. Since 2009, he is with Radio Waves Inc. , Billerica, Massachusetts. His current research interests include computational electromagnetics, optimizations in electromagnetics, ultrawide-band radio systems and multiple[1]input-multiple-output systems. Dr. Wu is a member of Sigma Xi Society and a member of Phi Kappa Phi Society.
