Perspectives, Science and Technologies for Novel Silicon on Insulator Devices

  • E-Book (pdf)
  • 344 Seiten
(0) Erste Bewertung abgeben
Alle Bewertungen ansehen
This proceedings volume contains the contributions of the speakers who attended the NATO Advanced Research Workshop on "Perspecti... Weiterlesen
CHF 77.00
Download steht sofort bereit
Informationen zu E-Books
E-Books eignen sich auch für mobile Geräte (sehen Sie dazu die Anleitungen).
E-Books von Ex Libris sind mit Adobe DRM kopiergeschützt: Erfahren Sie mehr.
Weitere Informationen finden Sie hier.
Bestellung & Lieferung in eine Filiale möglich


This proceedings volume contains the contributions of the speakers who attended the NATO Advanced Research Workshop on "Perspectives, Science and Technologies for Novel Silicon on Insulator Devices" held at the Sanatorium Pushcha OLema, Kyiv, th Ukraine from It" to 15 October 1998. This meeting was the second NATO Silicon on Insulator (SOl) Workshop to be held in st the Ukraine where the first meeting (Gurzuf, Crimea, 1 to 4th November 1994) focussed upon the physical and technical problems to be addressed in order to exploit the advantages of incorporating SOl materials in device and sensor technologies. On this occasion emphasis was placed upon firstly, promoting the use of SOl substrates for a range of novel device and circuit applications and secondly, addressing the economic issues of incorporating SOl processing technologies and device technologies within the framework of the resources available within the laboratories and factories of the Newly Independent States (NIS). The primary goal of both workshops has been the breaking of the barriers that inhibit closer collaboration between scientists and engineers in the NATO countries and the NIS. Indeed, it was a pleasure for attendees at the first meeting to renew acquaintances and for the first time attendees to make new contacts and enjoy the warm hospitality offered by our hosts in Kyiv. An outcome was the forging of new links and concrete proposals for future collaborations.


Preface. Committee Members. Invited Speakers. Workshop Photographs. Section 1: Innovations in Materials Technologies. 1.1. SMART-CUT® Technology: Basic Mechanisms and Applications; M. Bruel. 1.2. Polish Stop Technology for Silicon on Silicide on Insulator Structures; H.S. Gamble. 1.3. Homoepitaxy on Porous Silicon with a Buries Oxide Layer; Full-Wafer Scale SOI; S.I. Romanov, et al. 1.4. Structural and Electrical Properties of Silicon on Isolator Structures Manufactured on FZ- and CZ-Silicon by SMART-CUT Technology; V.P. Popov, et al. 1.5. Development of Linear Sequential Lateral Solidification Technique to Fabricate Quasi-Single-Crystal Super-Thin Si Films for High-Performance Thin Film Transistor Devices; A.B. Limanov, et al. Section 2: Economics and Innovation Applications. 2.1. Low Temperature Polysilicon Technology: A Low Cost SOI Technology? F. Plais, et al. 2.2. A Novel Low Cost Process for the Production of Semiconductor Polycrystalline Silicon from Recycled Industrial Waste; B.N. Mukashev, et al. 2.3. Tetrahedrally Bonded Amorphous Carbon for Electronic Applications; W.I. Milne. 2.4. Diamond Based Silicon-on-Insulator Materials and Devices; S. Bengtsson, M. Bergh. 2.5. Low-Temperature Processing of Crystalline Si Films on Glass for Electronic Applications; R.B. Bergmann, et al. 2.6. beta-SiC on SiO2 Formed by Ion Implantation and Bonding for Micromechanics Applications; C. Serre, et al. 2.7. Laser Recrystallized Polysilicon Layers for Sensor Applications: Electrical Piezoresistive Characterization; A.A. Druzhinin, et al. Section 3: CharacterisationMethods for SOI. 3.1. Optical Spectroscopy of SOI Materials; A. Pérez-Rodríguez, et al. 3.2. Computer Simulation of Oxygen Redistribution in SOI Structures; V.G. Litovchenko, A.A. Efremov. 3.3. Electrical Instabilities in Silicon-on-Insulator Structures and Devices During Voltage and Temperature Stressing; A.N. Nazarov, et al. 3.4. Hydrogen as a Diagnostic Tool in Analysing SOI Structures; A. Boutry-Forveille, et al. 3.5. Back Gate Voltage Influence on the LDD SOI NMOSFET Series Resistance Extraction from 150 to 300 K; A.S. Nicolett, et al. 3.6. Characterization of Porous Silicon Layers Containing a Buried Oxide Layer; S.I. Romanov, et al. 3.7. Total-Dose Radiation Response of Multilayer Buried Insulators; A.N. Rudenko, et al. 3.8. Recombination Current in Fully-Depleted SOI Diodes: Compact Model and Lifetime Extraction; T. Ernst, et al. 3.9. Investigation of the Structural and Chemical Properties of SOI Materials by Ellipsometry; L.A. Zabashta, et al. 3.10. Experimental Investigation and Modeling of Coplanar Transmission Lines on SOI Technologies for RF Applications; J. Lescot, et al. Section 4: Perspectives for SOI Structures and Devices. 4.1. Perspectives of Silicon-on-Insulator Technologies for Cryogenic Electronics; C. Claeys, et al. 4.2. SOI CMOS for High-Temperature Applications; J.P. Colinge. 4.3. Quantum Effect Devices on SOI Substrates with an Ultrathin Silicon Layer; Y. Omura. 4.4. Wafer Bonding for Micro-ElectroMechanical Systems (MEMS); C.A. Colinge. 4.5. A Com


Titel: Perspectives, Science and Technologies for Novel Silicon on Insulator Devices
EAN: 9789401142618
Format: E-Book (pdf)
Hersteller: Springer Netherlands
Genre: Technik
Veröffentlichung: 06.12.2012
Digitaler Kopierschutz: Wasserzeichen
Anzahl Seiten: 344
