Pipelined ADCs have seen phenomenal improvements in performance over the last few years. As such, when designing a pipelined ADC a clear understanding of the design tradeoffs, and state of the art techniques is required to implement today's high performance low power ADCs. Written for both researchers and professionals, Pipelined ADC Design and Enhancement Techniques provides:

i.) A tutorial discussion, for those new to pipelined ADCs, of the basic design and tradeoffs involved in designing a pipelined ADC

ii.) A detailed discussion of four novel silicon tested pipelined ADC topologies geared towards those looking to gain insight into state-of-the-art design in the area. The ADCs detailed include:

• An 11-bit 45MS/s ADC which rapidly digitally calibrates in the background both DAC and gain errors

• A 10-bit ADC with power scalable between 50MS/s (35mW) to 1kS/s (15µW)

• A 10-bit ADC for use in sub-sampled systems with a technique to eliminate the front-end sample-and-hold

• A 10-bit, 50MS/s ADC which uses a capacitive charge pump based approach to enable a very small power consumption of 9.9mW.

Inhalt
Pipelined ADC Design.- ADC Architectures.- Pipelined ADC Architecture Overview.- Scaling Power with Sampling Rate in an ADC.- State of the Art Pipelined ADC Design.- Pipelined ADC Enhancement Techniques.- Rapid Calibration of DAC and Gain Errors in a Multi-bit Pipeline Stage.- A Power Scalable and Low Power Pipelined ADC.- A Sub-sampling ADC with Embedded Sample-and-Hold.- A Capacitive Charge Pump Based Low Power Pipelined ADC.- Summary.
