Local Electrode Atom Probe Tomography

  • E-Book (pdf)
  • 318 Seiten
(0) Erste Bewertung abgeben
Alle Bewertungen ansehen
This book is the first, single-source guide to successful experiments using the local electrode atom probe (LEAP®) microscope.... Weiterlesen
E-Books ganz einfach mit der kostenlosen Ex Libris-Reader-App lesen. Hier erhalten Sie Ihren Download-Link.
CHF 119.90
Download steht sofort bereit
Informationen zu E-Books
E-Books eignen sich auch für mobile Geräte (sehen Sie dazu die Anleitungen).
E-Books von Ex Libris sind mit Adobe DRM kopiergeschützt: Erfahren Sie mehr.
Weitere Informationen finden Sie hier.


This book is the first, single-source guide to successful experiments using the local electrode atom probe (LEAP®) microscope. Coverage is both comprehensive and user friendly, including the fundamentals of preparing specimens for the microscope from a variety of materials, the details of the instrumentation used in data collection, the parameters under which optimal data are collected, the current methods of data reconstruction, and selected methods of data analysis. Tricks of the trade are described that are often learned only through trial and error, allowing users to succeed much more quickly in the challenging areas of specimen preparation and data collection. A closing chapter on applications presents selected, state-of-the-art results using the LEAP microscope.



Chapter 1. History of APT and LEAP
1.1 Introduction
1.2 Ancestry of the Local Electrode Atom Probe
1.2.1 Early History and the Field Electron Emission Microscope (~1935)
1.2.2 Field Ion Microscope: The First Images of Atoms (1955)
1.2.3 Atom Probe Field Ion Microscope (1967)
1.2.4 The Advent of Atom Probe Tomography
1.2.5 The Position Sensitive Atom Probe (1988)
1.2.6 Electron Beam Pulsed Atom Probe
1.2.7 The Scanning Atom Probe
1.2.8 The Local Electrode Atom Probe (2001)
1.3 The State of Instrumentation
1.3.1 The Growth of the Local Electrode Atom Probe
1.3.2 Laser Pulsing
1.3.3 Fundamental Considerations for Design of Instrumentation
1.3.4 Reflectron-Based Instruments
1.4 FIB-Based Specimen Preparation
1.5 Concluding Remarks

Chapter 2. Specimen Preparation
2.1 Introduction
2.2 Electropolishing
2.3 Needles versus Microtips
2.4 Electrostatic Discharge Considerations
2.5 Focused Ion Beam Methods
2.5.1 Capping Considerations & Damage
2.5.2 Standard Lift-Out Process
2.5.3 Sharpening Process
2.5.4 FIB Deprocessing
2.6 Hybrid Transmission Electron Microscopy / Atom Probe Tomography
2.7 Summary

Chapter 3. Design & Instrumentation
3.1 Introduction
3.2 How Atom Probes Work
3.3 LEAP Performance Parameters
3.3.1 Field of View
3.3.2 Mass Resolving Power
3.3.3 Data Collection Rate
3.3.4 Model Comparison
3.4. Instrumentation in the LEAP
3.4.1 Local Electrode
3.4.2 Detection and Imaging
3.4.3. Transfer and Storage of Consumables
3.4.4. Field Evaporation Systems
3.4.5 Ancillary Systems
3.5 Summary

Chapter 4. Data Collection
4.1 Introduction
4.2 Data Quality Considerations
4.3 Analysis Yield Considerations
4.4 Experimental Parameters
4.5 How to Start Your Investigation of Any New Material
4.6 Brief Overview of LEAP Operation: Data Collection
4.6.1 Voltage Acquisition
4.6.2 Laser Acquisition
4.6.3 Now You Are Atom Probing

Chapter 5. Data Processing and Reconstruction
5.1 Introduction
5.2 A Word on Data Files and Work Flow
5.3 Conversion from Detector Space to Specimen Space Coordinates
5.3.1 Selection of Depth and Areal Regions
5.3.2 Spectral Calibration
5.3.3 Chemical Identification & Ranging
5.3.4 Spatial Reconstruction: Projection and Depth Scaling
5.3.5 Wide Angle Reconstruction Protocols
5.3.6 Tangential Discontinuity
5.3.7 Reconstruction Explorer
5.3.8 Creation of ROOT and POS Files
5.4 Discussion of Spatial Resolution and Spatial Positioning
5.4.1 Spatial Resolution
5.4.2 Spatial Positioning (Non-Specimen Dependent)
5.4.3 Spatial Positioning (Specimen Dependent)
5.5 A Word on Density Relaxation
5.6 Reconstruction Case Study: NIST Standard Reference Material 2134
5.6.1 Reconstruction Parameter Discussion
5.6.2 Experiment and Analysis Details

Chapter 6. Selected Analysis Topics
6.1 Introduction
6.2 Spectral Analysis
6.2.1 Ranging
6.2.2 Practical Considerations for Detection Levels
6.2.3 Peak Decomposition
6.3 Concentration Space Analyses
6.3.1 Gridding, Voxels, and Delocalization
6.3.2 Interface Creation and Interfacial Roughness
6.3.3 Effects of Delocalization on Planar Surfaces
6.3.4 The Proximity Histogram
6.4 Solute Analysis: Cluster Detection Method
6.5 Spatial Distribution Maps
6.6 Application of Spatial Distribution Maps

Chapter 7. Applications of the Local Electrode Atom Probe
7.1 Metals
7.2 Catalytic Materials
7.3 Ceramic and Geological Materials
7.4 Semiconductor Materials
7.5 Organics and Biological Materials
7.6 Composite Structures/Devices
7.7 Conclusions

Appendix A. Data File Formats
Appendix B. Field Evaporation
Appendix C. Reconstruction Geometry
Appendix D. Mass Spectral Performance
Appendix E. Additional Considerations for LEAP Operation




Titel: Local Electrode Atom Probe Tomography
Untertitel: A User's Guide
EAN: 9781461487210
ISBN: 978-1-4614-8721-0
Digitaler Kopierschutz: Wasserzeichen
Format: E-Book (pdf)
Herausgeber: Springer
Genre: Technik
Anzahl Seiten: 318
Veröffentlichung: 12.12.2013
Jahr: 2013
Untertitel: Englisch
Dateigrösse: 10.4 MB
